Features: | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket | Supports DDR4 Memory, Dual Channel DDR4 5333+MHz (OC) | Enhanced Power Design | : 14+1+1 DRPS with 55A DrMOS, dual 8-pin CPU power connectors, Core Boost, Memory Boost | Premium Thermal Solution | : Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience | High Quality PCB | : 6-layer PCB made by 2oz thickened copper and server grade level material | Lightning Fast Game experience | : PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2 | Intel Turbo USB 3.2 Gen 2 | : Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds | 2.5G LAN with Wi-Fi 6E Solution | : Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection | AUDIO BOOST | : Reward your ears with studio grade sound quality for the most immersive gaming experience | Specification: | Chipset | INTEL Z790 | CPU SUPPORT | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors | LGA 1700 | Memory | 4x DDR4, Maximum Memory Capacity 128GB | Memory Support 5333/5200/5066/5000/4800/4600/4533/4400/4266/4000/3866/3733/3600/3466/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133(By JEDCE & POR) | Max. overclocking frequency: | • 1DPC 1R Max speed up to 5333+ MHz | • 1DPC 2R Max speed up to 4800+ MHz | • 2DPC 1R Max speed up to 4400+ MHz | • 2DPC 2R Max speed up to 4000+ MHz | Supports Dual-Channel mode | Supports non-ECC, un-buffered memory | Supports Intel® Extreme Memory Profile (XMP) | Onboard Graphics | 1x HDMI™ | 1x DisplayPort | Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz | Support DP 1.4, maximum resolution of 4K 60Hz | EXPANSION SLOT | 3x PCI-E x16 slot | 1x PCI-E x1 slot | PCI_E1 PCIe 5.0 supports up to x16 (From CPU) | PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) | PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) | PCI_E4 PCIe 3.0 supports up to x1 (From Chipset) | Storage | 4x M.2 slot | M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices | M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices | M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices | M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices | 6x SATA 6G port | RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices | USB | 4x USB 2.0 (Rear) | 4x USB 2.0 (Front) | 2x USB 3.2 Gen1 Type A (Rear) | 4x USB 3.2 Gen1 Type A (Front) | 1x USB 3.2 Gen2 Type A (Rear) | 1x USB 3.2 Gen2 Type C (Front) | 1x USB 3.2 Gen2x2 Type C (Rear) | LAN | Intel® 2.5Gbps LAN | WIRELESS / BLUETOOTH | Intel® Wi-Fi 6E | The Wireless module is pre-installed in the M.2 (Key-E) slot | Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps | Supports 802.11 a/ b/ g/ n/ ac/ ax | Supports Bluetooth® 5.3, FIPS, FISMA | Audio | Realtek® ALC897 Codec | 7.1-Channel High Definition Audio | Internal I/O | 1x Power Connector(ATX_PWR) | 2x Power Connector(CPU_PWR) | 1x CPU Fan | 1x Pump Fan | 6x System Fan | 2x Front Panel (JFP) | 1x Chassis Intrusion (JCI) | 1x Front Audio (JAUD) | 1x TBT connector (JTBT, supports RTD3) | 1x Tuning Controller connector(JDASH) | 2x Addressable V2 RGB LED connector (JARGB_V2) | 1x RGB LED connector(JRGB) | 1x TPM pin header(Support TPM 2.0) | 4x USB 2.0 | 4x USB 3.2 Gen1 Type A | 1x USB 3.2 Gen2 Type C | LED FEATURE | 4x EZ Debug LED | BACK PANEL PORTS | Keyboard / Mouse | DisplayPort | USB 2.0 | 2.5G LAN | Wi-Fi / Bluetooth | Audio Connectors | Flash BIOS Button | HDMI™ | USB 3.2 Gen 1 5Gbps (Type-A) | USB 3.2 Gen 2x2 20Gbps (Type-C) | USB 3.2 Gen 2 10Gbps (Type-A) | OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit | PCB Dimension | ATX | 243.84mmx304.8mm | Warranty | 3 Years | Note | *** Features, Price, Specifications are subject to change without notice.
