Features: | This document describes ValueRAM's KVR32N22S8/16 is a 2G x 64-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), Single Rank: | 1R | x 8,memory module, based on eight 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows | Power Supply: VDD = 1.2V Typical | VDDQ = 1.2V Typical | VPP = 2.5V Typical | VDDSPD = 2.2V to 3.6V | Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals | Low-power auto self refresh (LPASR) | Data bus inversion (DBI) for data bus | On-die VREFDQ generation and calibration | Single-rank | On-board I2 serial presence-detect (SPD) EEPROM | 16 internal banks; 4 groups of 4 banks each | Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS) | Selectable BC4 or BL8 on-the-fly (OTF) | Fly-by topology | Terminated control command and address bus | PCB: Height 1.23” (31.25mm) | RoHS Compliant and Halogen-Free
