Features: | Power Supply: | VDD = 1.2V Typical | VDDQ = | 1.2V Typical | VPP = | 2.5V Typical | VDDSPD = | 2.2V to 3.6V | Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals | Low-power auto self refresh (LPASR) | On-die VREFDQ generation and calibration | Single-rank | On-board I2 serial presence-detect (SPD) EEPROM | 16 internal banks; 4 groups of 4 banks each | Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS) | Selectable BC4 or BL8 on-the-fly (OTF) | Fly-by topology | Terminated control command and address bus | PCB: | Height 0.738” (18.75mm) | RoHS Compliant and Halogen-Free | This document describes ValueRAM's KVR32N22S8L/8WP is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM),1Rx8,VLP (very low profile) memory module, based on eight 1G x 8-bit FBGA components.The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:
