Features: | This document describes ValueRAM's KVR56S46BS8-16 is a 2G x 64-bit (16GB) DDR5-5600 CL46 SDRAM (Synchronous DRAM),1Rx8, memory module, based on eight 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-5600 timing of 46-45-45 at 1.1V. Each 262-pin SODIMM uses gold contact fingers. The electrical and mechanical specifications are as follows: | Power Supply: VDD = 1.1V Typical | VDDQ = 1.1V Typical | VPP = 1.8V Typical | VDDSPD = 1.8V to 2.0V | PCB: Height 1.18” (30.00mm) | RoHS Compliant and Halogen-Free
