Features: | Intel® Socket LGA 1700：Support 13th and 12th Gen Series Processors | Unparalleled Performance：Twin 16+1+１ Phases Digital VRM Solution | Dual Channel DDR5：4SMD DIMMs with XMP 3.0 Memory Module Support | Next Generation Storage：3PCIe 4.0 x4 M.2 Connectors | Advanced Thermal Design & M.2 Thermal Guard: To Ensure VRM Power Stability & M.2 SSD Performance | EZ-Latch Plus：PCIe 5.0 x16 Slot with Quick Release & Screwless Design | Fast Networks：2.5GbE LAN & Wi-Fi 6E 802.11ax | Extended Connectivity：DP, HDMI, Front USB-C® 5Gb/s, Rear USB-C® 20Gb/s | Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP | Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card | 8+8 phases parallel power design | Specification: | CPU | LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors | L3 cache varies with CPU | Chipset | Intel® Z790 Express Chipset | Memory | Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules | 4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory | Dual channel memory architecture | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | Support for Extreme Memory Profile (XMP) memory modules | Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: | 1 x HDMI port, supporting a maximum resolution | Support for HDMI 2.0 version and HDCP 2.3. | 1 x DisplayPort, supporting a maximum resolution | Support for DisplayPort 1.2 version and HDCP 2.3 | Audio | Realtek® Audio CODEC | High Definition Audio | 2/4/5.1/7.1-channel | Support for S/PDIF Out | LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) | Wireless Communication module | AMD Wi-Fi 6E RZ616 (MT7922A22M) | WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands | BLUETOOTH 5.2 | Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate | Expansion Slots | CPU: | 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) | For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. | Chipset: | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) | 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4) | 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3) | Support for AMD CrossFire™ technology (PCIEX16 and PCIEX4) | Storage Interface | 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) | 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) | 6 x SATA 6Gb/s connectors | USB | 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support | 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header | 1 x USB 3.2 Gen 2 Type-A ports (red) on the back panel | 6 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) | Chipset+2 USB 2.0 Hubs: | 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) | Internal I/O Connectors | 1 x 24-pin ATX main power connector | 2 x 8-pin ATX 12V power connectors | 1 x CPU fan header | 1 x water cooling CPU fan header | 3 x system fan headers | 1 x system fan/water cooling pump header | 2 x addressable LED strip headers | 2 x RGB LED strip headers | 3 x M.2 Socket 3 connectors | 1 x front panel header | 1 x front panel audio header | 1 x S/PDIF Out header | 1 x USB Type-C® header, with USB 3.2 Gen 1 support | 1 x USB 3.2 Gen 1 header | 2 x USB 2.0/1.1 headers | 1 x serial port header | 2 x Thunderbolt™ add-in card connectors | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | 1 x reset button | 1 x Q-Flash Plus button | 1 x reset jumper | 1 x Clear CMOS jumper | Back Panel Connectors | 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support | 1 x USB 3.2 Gen 2 Type-A port (red) | 4 x USB 3.2 Gen 1 ports | 4 x USB 2.0/1.1 ports | 2 x SMA antenna connectors (2T2R) | 1 x HDMI 2.0 port | 1 x DisplayPort | 1 x RJ-45 port | 3 x audio jacks | I/O Controller | iTE® I/O Controller Chip | H/W Monitoring | Voltage detection | Temperature detection | Fan speed detection | Water cooling flow rate detection | Fan fail warning | Fan speed control | BIOS | 1 x 256 Mbit flash | Use of licensed AMI UEFI BIOS | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | Unique Features | Support for GIGABYTE Control Center (GCC) | Support for Q-Flash | Support for Q-Flash Plus | Support for Smart Backup | Bundled Software | Norton® Internet Security (OEM version) | LAN bandwidth management software | Operating System | Support for Windows 11 64-bit | Support for Windows 10 64-bit | Form Factor | ATX Form Factor; 30.5cm x 24.4cm | Warranty | 3 Years | Note | *** Features, Price, Specifications are subject to change without notice.
